The EdgeSpec 3D solution has an assortment of different tools to provide a fast and intuitive means of assessing the scanned object.
Solution Specifications
- EdgeSpec M1-95-165-BD
- High Resolution HD Camera
- Diameter: 95mm (3 3/4in)
- Working Range: 150mm to 400mm (6in to 15in)
- Length: 165mm (6 1/2in)
- Variable lighting control
- Maximum Cable Length is 9m (30ft)
This solution takes into account that customer driven applications
generally have specific requirements. The EdgeSpec M Series is
designed to be a universal inspection tool. Given its minimal
space requirements, the scanner can easily be incorporated into
any new tooling manipulator without the need for any formal
integration. The system requires no calibration and can simply be
placed on any manipulator of choice to begin scanning.
Individual scans can be combined automatically to create a larger
area scan of any space with our proprietary algorithms.
Solution Specifications
- EdgeSpec S1-95-315-BD
- High Resolution HD Camera
-
Overall Size (LxWxH): 318 mm x 153 mm x
130 mm (12 1/2in x 6in x 5in) -
Lower Diameter x Length: 95mm x 203 mm
(3 3/4in x 8in) - Working Range: 150mm to 400mm (6in to 15in)
- Variable lighting control
- Maximum Cable Length is 9m (30ft)
The EdgeSpec S Series is designed with a minimum diameter and
incorporates a failsafe housing to mitigate any potential
introduction of unwanted foreign material. The system requires no
calibration and can simply be place in any separator to begin
scanning.
This solution allows for easy installation and inspection of steam
separators.
Individual scans can be combined to create a larger area scan of
any steam generator with our proprietary algorithms.
Solution Specifications
- EdgeSpec R1-120-290-BD
- High Resolution HD Camera
- Width: 120mm (4 3/4in)
- Working Range: 100mm to 390mm (4in to
15 1/4in) - Length: 290mm (11 1/2in)
- Variable lighting control
- Maximum Cable Length is 9m (30ft)
The EdgeSpec R Series has been designed to provide an option for
industrial applications where a means of assessing surface
integrity of various different surfaces such as roads and airport
runways is required.
The EdgeSpec R Series is designed to function as a mobile
acquisition solution. This solution can be easily adapted to any
fixed point on a vehicle, track or rail and can be used to collect
accurate repeatable data without the need of constant distance
measuring information (DMI). The system requires no calibration
and can simply be placed on the vehicle of choice to begin data
acquisition. The system can aquire data at long and short
wavelengths for IRI and texture assessments.
